LUXA 103 presence detectors for indoor and outdoor use: The new definition of standard
Theben LUXA 103 presence detectors are a versatile device family for efficient lighting and HVAC control both indoors and outdoors. The devices with a circular detection area are ideal for use in individual and open-plan offices, meeting rooms, storerooms, basements and toilets. Special presence detectors for corridors have a rectangular detection area. All devices can be configured via an app and controlled remotely and they are simple to install.The surface-mounted devices in black, white or grey blend into any design concept.
The highlights of the LUXA 103 presence detectors at a glance:
- Timelessly elegant, compact design
- Circular or rectangular detection area
- Convenient setting via an app and remote control, only remote control or potentiometers
- Simple installation and wiring
- Presence detector family with surface-mounted devices, combination devices for ceiling installation and flush mounting as well as presence detectors for corridors and hallways
- Surface-mounted devices available in black, white and grey
- Device variant with second channel for HVAC control
- Integrated button input
- Can be networked with other LUXA 103 devices or theMura slave wall detectors
- Perfect for switching high LED loads of up to 400 W
- Protection class IP 54 for use outdoors and in wet rooms
- Numerous comfort functions, such as pulse function, teach-in function, test function, staircase light function
Wide range of applications
LUXA 103 presence detectors offer a huge variety of applications for efficient lighting control indoors and outdoors. Here are some examples:
Open-plan office
Enjoy maximum flexibility thanks to the integrated button input and the option for parallel switching with other LUXA 103 devices or theMura slave wall detectors. This also makes the presence detectors suitable for larger offices or for use on staircases.
Individual offices
For energy-saving lighting control that reliably switches off the light when leaving the office (e.g. for meetings). In addition to energy savings, the presence detectors from the LUXA 103 series offer high reliability for users.
Staircases
The pulse function allows the presence detectors to be built into existing electrical installations with staircase light timer switches without the need for expensive adjustments.
Changing rooms
For reliable, presence-based lighting control in changing rooms with showers, a high protection class is absolutely essential. In these kinds of facilities, presence detectors are at risk of being exposed to splash water. The entire LUXA 103 series has a protection rating of IP 54 for use in wet rooms and outdoors.
Hallways and corridors
LUXA 103 corridor presence detectors with a rectangular detection area provide one channel for lighting control. They are available as a surface-mounted device as well as a combination device for ceiling installation/flush mounting.
Toilets
For enclosed spaces, we recommend our LUXA 103 variants with a second channel for ventilation control.
Protection class IP 54: perfect for wet rooms and outdoor areas
Protection class IP 54 means that all LUXA 103 presence detectors can be used in wet rooms and outdoors without any issues. For example, covered building entrances as well as covered terraces and balconies can be illuminated when presence is detected.
Easy programming via an app and remote control
It is particularly easy to program LUXA 103 presence detectors. The best way to do this is to use the theSenda B remote control in combination with the free theSenda Plug app. The parameters entered are sent by Bluetooth to the theSenda B remote control and from there are transmitted by infrared to the detector. This means all LUXA 103 devices can be configured and operated easily, quickly and safely.
Do you prefer a classic approach to programming? Then simply use the integrated potentiometers to configure the device. The theSenda Plug app for iOS and Android automatically displays all installed detectors. Flexible parameter setting means that parameter sets can be saved specifically according to the customer, be filed in parameter libraries or be established externally and imported. This means that identical parameters can be set quickly, even in larger properties with many detectors.
This is how customised presence detector installation can be!
Simple installation and wiring
LUXA 103 presence detectors essentially redefine simple installation and wiring. The connectors of the surface-mounted devices are installed according to the plug-in socket principle. The plug-in terminals of the ceiling and flush-mounted devices have been integrated at a 45° angle. Both simplify installation and wiring significantly, which in turn reduces installation costs. A small measure with a big impact. Typical Theben!
 |
 |
|
As with a socket, the connectors of the LUXA 103 surface-mounted devices are installed in the surface-mount frame. |
The plug-in terminals of the ceiling and flush-mounted devices have been integrated at a 45° angle. This makes it much easier to install the cables in the device. |
Technical data and function description of LUXA 103 presence detectors & corridor presence detectors
Presence detectors (circular detection area)
Corridor sensors (rectangular detection area)
Technical data and function description of LUXA 103 presence detectors & corridor presence detectors:
- LUXA 103 S360-100-12 DE-UP WH
Ceiling/flush-mounted installation, 1 channel, circular detection area - LUXA 103 S360-100-12 AP WH
Surface-mounted installation, 1 channel, circular detection area - LUXA 103 S360-100-28 DE-UP WH
Ceiling/flush-mounted installation, 1 channel, rectangular detection area - LUXA 103 S360-100-28 AP WH
Surface-mounted installation, 1 channel, rectangular detection area - LUXA 103 S360-101-12 DE-UP WH
Surface-mounted installation, 1 channel, rectangular detection area - LUXA 103 S360-101-12 AP WH
Ceiling/flush-mounted installation, 2 channels, circular detection area
